Model | 2.5mm2 | 4mm2 | 6mm2 | 10mm2 |
Cable Construction | ||||
Conductor | Stranded tinned copper | |||
Stranding | 45/0.25±0.01mm | 56/0.285±0.01mm | 78/0.295±0.01mm | 132/0.295±0.01mm |
Diameter | 2.4mm | 2.4mm | 3.0mm | 4.1mm |
PrimaryInsulation | XLPE | |||
Minimum Average Thickness | 0.7mm | 0.7mm | 0.7mm | 0.7mm |
PrimaryInsulation Color | Black | |||
Secondary Insulation | XLPE | |||
Minimum Average Thickness | 0.8mm | 0.8mm | 0.8mm | 0.8mm |
Secondary Insulation Color | Â Red/Black | |||
Outer Diameter |  5±0.15mm |  6.1±0.15mm |  6.1±0.15mm | 7.4±0.2mm |
Electrical Characteristics | ||||
Voltage Rating | 1000V | |||
Ambient Temperature | -40°C up to 90°C | |||
Insulation Resistance At 20℃ | ≥ 640 MΩ.km | ≥ 580 MΩ.km | ≥ 500 MΩ.km | ≥ 420 MΩ.km |
Current carrying capacity AT 60℃ | 41A | 55A | 70A | 98A |
Spark test | 10000 VAC | |||
Voltage Withstand | 6500 VAC | |||
ConductorResistanceAT 20℃ | ≤ 8.21 Ω/km | ≤ 5.09 Ω/km | ≤ 3.39 Ω/km | ≤ 1.95 Ω/km |
Other Characteristics | ||||
Bending Radius Dynamic | ≥ 5 X O.D. | |||
Bending Radius Static |  ≥ 4 X O.D. | |||
Ozone resistant | EN60811-403 Method A;EN 50396 8.1.3 Method B | |||
Low smoke emission | EN61034-2,light transmittance ≥ 60% | |||
Weathering/UL resistance | EN50289-4-17 | |||
Halogen free | IEC 60754-1 | |||
Flame retardant | IEC 60332-1-2 |
Model | 2.5mm2 | 4mm2 | 6mm2 | 10mm2 |
Cable Construction | ||||
Conductor | Stranded tinned copper | |||
Stranding | 45/0.25±0.01mm | 56/0.285±0.01mm | 78/0.295±0.01mm | 132/0.295±0.01mm |
Diameter | 2.4mm | 2.4mm | 3.0mm | 4.1mm |
PrimaryInsulation | XLPE | |||
Minimum Average Thickness | 0.7mm | 0.7mm | 0.7mm | 0.7mm |
PrimaryInsulation Color | Black | |||
Secondary Insulation | XLPE | |||
Minimum Average Thickness | 0.8mm | 0.8mm | 0.8mm | 0.8mm |
Secondary Insulation Color | Â Red/Black | |||
Outer Diameter |  5±0.15mm |  6.1±0.15mm |  6.1±0.15mm | 7.4±0.2mm |
Electrical Characteristics | ||||
Voltage Rating | 1500V | |||
Ambient Temperature | -40°C up to 90°C | |||
Insulation Resistance At 20℃ | ≥ 640 MΩ.km | ≥ 580 MΩ.km | ≥ 500 MΩ.km | ≥ 420 MΩ.km |
Current carrying capacity AT 60℃ | 41A | 55A | 70A | 98A |
Spark test | 10000 VAC | |||
Voltage Withstand | 6500 VAC | |||
ConductorResistanceAT 20℃ | ≤ 8.21 Ω/km | ≤ 5.09 Ω/km | ≤ 3.39 Ω/km | ≤ 1.95 Ω/km |
Other Characteristics | ||||
Bending Radius Dynamic | ≥ 5 X O.D. | |||
Bending Radius Static |  ≥ 4 X O.D. | |||
Ozone resistant | EN60811-403 Method A;EN 50396 8.1.3 Method B | |||
Low smoke emission | EN61034-2,light transmittance ≥ 60% | |||
Weathering/UL resistance | EN50289-4-17 | |||
Halogen free | IEC 60754-1 | |||
Flame retardant | IEC 60332-1-2 | |||
Package type | 300m/roll | 250m/roll | 200m/roll | 100m/roll |
Weight | 13KG | 17KG | 16KG | 13KG |
