Cudy AX3000 Gigabit Wall-Plate Wi-Fi 6 Access Point Model: AP3000 Wall

Price:

$ 57.25
  2. Shop
  3. Cudy AX3000 Gigabit Wall-Plate Wi-Fi 6 Access Point Model: AP3000 Wall
Cudy 2-IN-1 SMB Router / AP Controller Model: C200P
Cudy 2-IN-1 SMB Router / AP Controller Model: C200P
$ 48.75
$ 48.75
Cudy 8-Port 10/100M Industrial Switch Model: IF1008
Cudy 8-Port 10/100M Industrial Switch Model: IF1008
$ 30.00
$ 30.00
Coming Soon

Cudy AX3000 Gigabit Wall-Plate Wi-Fi 6 Access Point Model: AP3000 Wall

https://www.danoun-tech.com/web/image/product.template/2896/image_1920?unique=dd844f3

$ 57.25 57.25 USD $ 57.25

$ 57.25

Not Available For Sale

  • Brand

This combination does not exist.

Contact Us
Brand: Cudy
Cudy
Cudy
Model Number :
AP3000 Wall
Categories :
Access Points
Tags :

Cudy AX3000 Gigabit Wall-Plate Wi-Fi 6 Access Point Model: AP3000 Wall

An in-wall WiFi 6 AP with a built-in 5-GbE switch ideal for covering a room or ensuite in hospitality environments. One PoE output allows for connecting an IP phone or other PSE-enabled devices.

  •  1.3 GHz Dual-Core CPU
  •  4-Stream Dual-Band Wi-Fi 6
  •  2402 Mbps + 574 Mbps Wi-Fi 1
  •  1× GbE PoE In, 1× GbE PoE Out, 3× GbE
  •  802.3at/af, Passive PoE
  •  PoE Passthrough
  •  Watchdog, Schedule Reboot
  •  Covers 60 m² (650 ft²) 2
  •  60 Connected Devices 3
CPUCPU Details1.3 GHz Dual-Core CPU
Memory/StorageFlash/ROM128 MB (1 Gbit) NAND
DDR/RAM256 MB (2 Gbit) DDR3
Wireless5 GHz Wi-Fi Speed2402Mbps
2.4 GHz Wi-Fi Speed574 Mbps
5 GHz Wi-Fi Streams2T2R (2×2 MIMO) with an Extra Stream
2.4 GHz Wi-Fi Streams2T2R (2×2 MIMO)
Wi-Fi Antennas3× Internal
5 GHz Antenna Gain Max7.08dBi (US), 6.52dBi (EU)
2.4 GHz Antenna Gain Max3.17dBi
FEM or PA/LNA
  • 5 GHz: 3× Internal
  • 2.4 GHz: 2× Internal
BeamformingTrue
Range PerformanceMax: 80 m (262 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
Wall PerformanceTwo wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'')
InterfacesGigabit RJ45 Ports5
Ethernet NotesThe port on the back accepts PoE powering. One port on the front bottom supports PoE passthrough
LEDSystem
Physical Buttons
  • Reset Button
  • LED On/Off Button (Configurable to control LED and Wi-Fi)
Power InputPoE via Ethernet Port
PowerPower Methods
  • Passive PoE
  • 802.3at/af PoE
Passive PoE48V
Max Power Consumption (W)12 W (48 V PoE)
Idle Power Consumption (W)5 W (48 V PoE)
ReliabilityAdvancedHardware Watchdog
EMSESD: Contact: 4kV; Air: 8kV
EnvironmentOperating Temperature: 0 ℃ ~ 40 ℃ (14 ℉ ~149 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
CertificationsFCC, CE
MechanicalInstallationWall-mount
Dimension143×86×27.6 mm
5.63×3.39×1.09 inches
Product Weight298.6 g (10.53 oz.)

WirelessWi-Fi StandardsWi-Fi 6
Max Wi-Fi Modulation1024-QAM
Wi-Fi Efficiency
  • OFDMA
  • MU-MIMO
  • BSS Color
Max Capacity256
Recommended Client Upper Limit60
Max Wi-Fi Channel Width160 MHz
Wi-Fi SecurityWPA/WPA2/WPA3
Multi-SSID (Max Number)8 SSIDs (Up to 4 SSIDs on each band)
GeneralOperation ModesAccess Point
MeshCudy Mesh
Mesh Backhaul
  • Wireless Backhaul
  • Wired Backhaul
Multi-Band BackhaulTrue
NetworkDHCPServer
IP VersionsIPv4
IGMPIGMP Snooping
UtilitiesWake on LANTrue
ManagementAll Devices ManagementWi-Fi Time Schedule
SystemLED ControlTrue
Local Control Method
  • Config Web Page
  • App Control
Remote Control Method
  • Config Page via HTTPS
  • App Control
Firmware Upgrade
  • Local Update
  • App (Over the Air)
  • Online Update
Reliability
  • Timed Reboot
  • Backup and Restore
Diagnostic Tools
  • Diagnosis
  • Ping
  • Traceroute
  • NSLookup
  • System Log




AP3000_Wall_Datasheet.pdf
Download
