Cudy 2-IN-1 SMB Router / AP Controller Model: C200P

https://www.danoun-tech.com/web/image/product.template/2895/image_1920?unique=52e5a4b

$ 48.75 48.75 USD $ 48.75

$ 48.75

Not Available For Sale

  • Brand

This combination does not exist.

Contact Us
Brand: Cudy
Cudy
Cudy
Model Number :
C200P
Categories :
Access Points
Tags :

Cudy 2-IN-1 SMB Router / AP Controller Model: C200P

A Gigabit router working as the controller of Cudy Access Points in whole-home Wi-Fi demands, feautring four PoE outputs and Cudy Mesh features.

  •  4× GbE with 802.3at/af Mode A PoE
  •  1× Gigabit Ethernet Port
  •  1× USB 3.0 Port
  •  60W Power Supply
  •  Manage 200 APs 1
  •  Captive Portal
  •  Cudy Mesh, VPN Server and Client


CPUCPU Details880 MHz Dual-Core
Memory/StorageFlash/ROM16 MB (128 Mbit) NOR
DDR/RAM256 MB (2 Gbit) DDR3
InterfacesGigabit RJ45 Ports5
Gigabit RJ45 PoE Ports#2~#5
Max Power on a Single PoE Ports30W
PoE Ports NotesThe PoE ports comply with IEEE 802.3at/af standards.
Ethernet Notes1× WAN Port, 4× LAN Ports
USB-A 3.0 Ports1
LED
  • System
  • PoE Max Status
  • Link/ACT/PoE Status of Each PoE Port
Physical ButtonsReset Button
Power InputDC Jack
PowerPower Methods
  • DC
  • 802.3at/af PoE
  • Passive PoE
DC54V 1.11A
Passive PoE24/48V
Power AdapterInput: 100 ~ 240 V, 50 Hz AC
Output: 54V 1.11A DC
Max Power Consumption (W)Total: 60W
PoE: 55W
PoE (when USB Device is plugged in): 50W
No PoE: 5W
Idle Power Consumption (W)2W
ReliabilityEMSIEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV
EnvironmentOperating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Operating Humidity: 5% ~ 95% non-condensing
Storage Humidity: 0% ~ 100% non-condensing
Grounding MethodsGrounding Point
CertificationsFCC, CE
MechanicalInstallation
  • Desktop
  • Wall-mount
Casing MaterialMetal
Dimension190×100×28 mm
7.48×3.94×1.1 inches
GeneralWAN Mode
  • DHCP
  • Static IP
  • PPPOE
Recommended Number of APs1. Main Router and AP Controller Mode: 10
2. AP Controller Mode: 200*
* If using the external portal server feature, it is recommended to manage fewer than 200 APs.
Recommended Number of Clients1. Main Router and AP Controller Mode: 100
2. AP Controller Mode: Not limited by controller
NetworkQoSRate Limiting
DHCP
  • Address Reservation
  • DHCP Client List
  • Server
IP VersionsIPv4/IPv6
IPv6 Protocols
  • Relay
  • Dynamic (SLAAC/DHCPv6)
  • Static (Fixed IP)
  • Passthrough
  • 464XLAT
  • MAP-E
  • DS-Lite
TTL Customization
  • Extend
  • Spoof
  • Custom
IGMP
  • IGMP Proxy
  • IGMP Snooping
Forwarding
  • Port Forwarding
  • Port Triggering
  • UPnP
  • DMZ
Firewall
  • SPI Firewall
  • DoS Protection
  • Block PING
Application Layer Gateway
  • IPSec Passthrough
  • L2TP Passthrough
  • PPTP Passthrough
  • FTP Passthrough
  • TFTP Passthrough
  • H323 Passthrough
  • SIP Passthrough
  • RTSP Passthrough
UtilitiesVPN Server
  • WireGuard
  • OpenVPN
  • IPsec
  • Zerotier
  • PPTP
  • L2TP
VPN Client
  • WireGuard
  • OpenVPN
  • IPsec
  • Zerotier
  • PPTP
  • L2TP
VPN Performance
  • OpenVPN Client (UL/DL): 22 / 24.7 Mbps
  • OpenVPN Server (UL/DL): 22 / 20.9 Mbps
  • WireGuard Client (UL/DL): 142 / 233.9 Mbps
  • WireGuard Server (UL/DL): 213 / 152 Mbps
Max Concurrent VPN Tunnels
  • IPSec: 20
  • PPTP/L2TP: 16
  • OpenVPN: 16
DNS Options
  • DNS over TLS
  • Manual DNS
  • Rebind Protection
  • Override Clients' DNS
DNS over TLS Providers
  • Cloudflare
  • Google
  • Quad9
  • Custom
USB FunctionsSamba Server
Wake on LANTrue
Online DetectionTrue
ManagementAll Devices Management
  • Wi-Fi Time Schedule
  • MAC Filter
  • IP/MAC Binding
Per-Devices Management
  • Internet On/Off
  • VPN On/Off
  • Online Time Schedule
  • Device Rename
Content Management
  • Domain Filter
  • IP Filter
AP ManagementCaptive Portal, Multi-SSID (Up to 4 SSIDs on each band)
SystemLocal Control MethodConfig Web Page
Remote Control Method
  • Config Page via HTTPS
  • TR069/TR098/TR111/TR143/TR181
Firmware UpgradeLocal Update
Reliability
  • Timed Reboot
  • Backup and Restore
Diagnostic Tools
  • Diagnosis
  • Ping
  • Traceroute
  • NSLookup
  • System Log
DashboardPanel
  • Internet Status
  • WAN Status
  • LAN Status
  • VPN Status
  • DHCP Server Status
  • System Version
  • AP Management


C200P_1.0_Datasheet.pdf
Download
