Step DOWN Converter DC to DC from 36V to 3V 3A
The step-down converter DC to DC from 36V to 3V 3A is a highly efficient and reliable power converter designed to convert a higher DC voltage (36V) to a lower DC voltage (3V) at a maximum current of 3A. This converter is ideal for a wide range of applications where it is necessary to power devices or systems that operate at a lower voltage from a higher voltage source.
*Specifications:*
- Input Voltage Range: 30V to 36V
- Output Voltage: 3V ± 0.2V
- Output Current: 0 to 3A
- Efficiency: >90%
- Switching Frequency: 150kHz
- Ripple and Noise: <50mV
- Input Protection: Reverse Polarity Protection, Over-Voltage Protection
- Output Protection: Short Circuit Protection, Over-Current Protection
- Operating Temperature: -40°C to +85°C
- Dimensions: 50mm x 30mm x 15mm
- Weight: 50g
