Kind of meter
digital, pincers type
Max. diameter of measured cable
28mm
Kind of display used
LCD
Display parameters
(4000)
DC current measuring range
40A/400A
AC current measuring range
(1) indirect measurement)
40A/400A
DC current measuring accuracy
±(2,5% + 5 digits)
AC current measuring accuracy
±(2,5% + 5 digits)
DC voltage measuring range
400mV/4V/40V/400V/600V
DC voltage measuring accuracy
±(0,5% + 2 digits)
AC voltage measuring range
4V/40V/400V/600V
AC voltage measuring accuracy
±(0,8% + 5 digits)
True effective value measurement
True RMS
Resistance measuring range
400Ω/4kΩ/40kΩ/400kΩ/40MΩ
Resistance measuring accuracy
±(0,8% + 2 digits)
Frequency measuring range
10...10MHz
Duty cycle factor
0.1...99.9%
Continuity test
acoustic indication, <10Ω
Test
diodes
Pollution degree
2
Dimensions
215x63x36mm
Weight with battery
235g
Measurement
AC current, AC voltage, continuity, DC current, DC voltage, duty cycle, frequency, resistance
Conform to the norm
CAT II 600V
CAT III 300V
EN 61010
