Cudy N300 Wi-Fi Router, Model: WR300
● Wi-Fi up to 300 Mbps
● Four 10/100 Mbps Ethernet Ports
● WireGuard/L2TP/PPTP VPN Client
● Cudy Mesh Satellite
● Router/AP/RE/WISP/Mesh Satellite Multi-Mode
● Reset Button
Specifications:
Hardware Specs
| Model Version | WR300 1.0 | |
|---|---|---|
| CPU | CPU Details | 580 MHz Single-Core, MIPS24KEC |
| Memory/Stroage | Flash/ROM | 8 MB (64 Mbit ) NOR |
| DDR/RAM | 64 MB (512 Mbit) DDR3 | |
| Wireless | 2.4 GHz Wi-Fi Speed | 300 Mbps |
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
| Wi-Fi Antennas | 2× Fixed | |
| Range Performance | Max: 100 m (328 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. | |
| Wall Performance | Two wooden walls with thickness < 3.8 cm (1.5'') One concrete wall with thickness < 10 cm (4'') | |
| Wi-Fi Transmission Power |
| |
| Interfaces | 10/100 Mbps RJ45 Ports | 4 |
| Ethernet Notes | 1× WAN port, the rest are LAN ports | |
| LED | System | |
| Physical Buttons |
| |
| Power Input | DC Jack | |
| Power | Power Methods | DC |
| DC | 5V 1A | |
| Power Adapter | Input: 100 ~ 240 V, 50/60 Hz AC Output: 5V 1A DC | |
| Reliability | Environment |
|
| Mechanical | Installation | Desktop |
| Dimension | 118×80×27.5 mm 4.65×3.15×1.08 inches | |
| Product Weight | EU: 120 g (4.23 oz.) | |
| Package Content |
| |
| Ordering Informaiton | Retail Package Weight | EU: 360 g (4.23 oz.) |
| Retail Package Dimension | 176×140.5×56 mm 6.93×5.53×2.2 inches | |
| Units per Carton | 40 | |
| Carton Dimension | 60×30×37.5 cm | |
| Carton Gross Weight | EU: 15.1 kg (33.29 lbs) | |
| Carton Net Weight | EU: 14.1 kg (31.09 lbs) |
| Model Version | WR300 1.0 | |
|---|---|---|
| Wireless | Wi-Fi Standards | Wi-Fi 4 |
| Max Capacity | 64 | |
| Recommended Client Upper Limit | 30 | |
| Max Wi-Fi Channel Width | 40 MHz | |
| Wi-Fi Security | WPA-PSK (WPA/WPA2) | |
| Guest Network | 2.4 GHz | |
| WPS | true | |
| General | Operation Modes |
|
| Mesh | Cudy Mesh | |
| Mesh Backhaul |
| |
| WAN Mode |
| |
| Network | QoS | Per-User Rate Limiting |
| DHCP |
| |
| IP Versions | IPv4/IPv6 | |
| IPv6 Protocols |
| |
| IPTV/VLAN |
| |
| TTL Customization |
| |
| IGMP |
| |
| Forwarding |
| |
| Firewall |
| |
| Application Layer Gateway |
| |
| Utilities | VPN Client |
|
| VPN Performance |
| |
| DNS Options |
| |
| DNS over TLS Providers |
| |
| Wake on LAN | true | |
| Online Detection | true | |
| Management | All Devices Management |
|
| Per-Devices Management |
| |
| Content Management |
| |
| System | LED Control | true |
| Local Control Method | Config Web Page | |
| Remote Control Method |
| |
| Firmware Upgrade | Local Update | |
| Reliability |
| |
| Diagnostic Tools |
| |
| Languages |
| |
| Dashboard | Panel | Internet Status, Mesh Status, Devices Management, WAN Status, LAN Status, WISP Status, Wi-Fi Status, VPN Status, DHCP Server Status, System Version |
| Charts | Mesh Topology, Internet Speed, WISP Speed, Wi-Fi Spe |
Software Specs
| Model Version | WR300 1.0 | |
|---|---|---|
| Wireless | Wi-Fi Standards | Wi-Fi 4 |
| Max Capacity | 64 | |
| Recommended Client Upper Limit | 30 | |
| Max Wi-Fi Channel Width | 40 MHz | |
| Wi-Fi Security | WPA-PSK (WPA/WPA2) | |
| Guest Network | 2.4 GHz | |
| WPS | true | |
| General | Operation Modes |
|
| Mesh | Cudy Mesh | |
| Mesh Backhaul |
| |
| WAN Mode |
| |
| Network | QoS | Per-User Rate Limiting |
| DHCP |
| |
| IP Versions | IPv4/IPv6 | |
| IPv6 Protocols |
| |
| IPTV/VLAN |
| |
| TTL Customization |
| |
| IGMP |
| |
| Forwarding |
| |
| Firewall |
| |
| Application Layer Gateway |
| |
| Utilities | VPN Client |
|
| VPN Performance |
| |
| DNS Options |
| |
| DNS over TLS Providers |
| |
| Wake on LAN | true | |
| Online Detection | true | |
| Management | All Devices Management |
|
| Per-Devices Management |
| |
| Content Management |
| |
| System | LED Control | true |
| Local Control Method | Config Web Page | |
| Remote Control Method |
| |
| Firmware Upgrade | Local Update | |
| Reliability |
| |
| Diagnostic Tools |
| |
| Languages |
| |
| Dashboard | Panel | Internet Status, Mesh Status, Devices Management, WAN Status, LAN Status, WISP Status, Wi-Fi Status, VPN Status, DHCP Server Status, System Version |
| Charts | Mesh Topology, Internet Speed, WISP Speed, Wi-Fi Speed |
